Warner Electric ERD Size 060 to 300 User Manual
Page 10
2 Warner Electric Europe • +33 (0)2 41 21 24 24
P-2060-WE • 2/13
We,
WARNER ELECTRIC EUROPE, 7, rue Champfleur, B.P. 20095, F-49182 St Barthélemy d’Anjou Cedex
declare that the combined clutches and brakes are made in our factory from St Barthélemy d’Anjou,
and hereafter designated :
EM and EMER
are exclusively designed for incorporation into a machine and to be assembled with other equipments to create a machine. The operation of
the product is submitted to the conformity of the complete equipment, following the provisions of the machinery directive 89/392/EEC and if
electric to the EMC directive 89/336 /EEC.
The conformity of the electric units to the Low Voltage directive 72/23 is supported by the full respect of the following standards : NFC 79300
and VDE 05808/8.65.
Drawn up in St Barthélemy d’Anjou, July 2002
E. PRAT, General Managing Director
CONTENTS
1
Technical specifications
2
2
Precautions and restrictions on use
2
2.1
Restrictions on use
2
2.2
Precautions and safety measures
2-3
3
Installation
3
3.1
Transport - storage
3
3.2
Handling
3
3.3
Installing
3
4
Maintenance
3
4.1
Adjusting the airgap
3
4.2
Maintenance
3
4.3
Spare parts
4
5
Electrical connection
4
5.1
Important recommendations
4
5.2
Power supply
4
6 Options
4
6.1
Torque adjustment
4
6.2
Detection kit
5
6.3
Hand release kit
5
7
Appendices
6
7. 1
ERD VAR00 and VAR02
7
7.2
Options
7
1
Technical specifications VAR00, VAR02
Table 1
ERD Size
60
100
170
300
Nominal torque (STANDARD version)
Nm
Nominal airgap +0,1/-0,05
mm
Pull-in airgap max.
mm
Nominal torque (HIGH TORQUE version) Nm
Tightening torque of screws
Nm
60
0,3
0,8
80
24
100
0,3
0,9
130
24
170
0,3
0,9
220
24
300
0,3
1
400
48
ERDD HT Size
120
200
340
600
Nominal torque (HIGH TORQUE version) Nm
Nominal airgap +0,1/-0,05
mm
Pull-in airgap max.
mm
Tightening torque of screws
Nm
160
0,3
0,8
24
260
0,4
0,9
24
440
0,4
0,9
24
800
0,4
1
48
2
Precautions and restrictions on use
2.1
Restrictions on use
The equipment is designed for dry
running.
Exceeding the maximum rotation speeds stated
in the catalogue invalidates the warranty.
The equipment can be fitted either horizontally or
vertically. The ERDD and HT version can only be
fitted horizontally.
This equipment is designed for an ambient
temperature of 40° maximum (155°C cladding
class).
2.2
Precautions and safety measures
During maintenance, ensure that the Mechanism
to be braked by the equipment is at rest and
that there is no risk of accidental start-up.
All intervention have to be made by qualified
personnel, owning this manual.
Any modification made to the brake without
the express authorisation of a representative of
Warner Electric, in the same way than any use
out of the contrac tual specifications accepted by
“Warner Electric”, will result in the warranty being
invalidated and Warner Electric will no longer be
liable in any way with regard to conformity.
