Warner Electric AT Clutch – Major Service Sizes 25, 55, 115 - Manual (Page 11)

Component Parts
ATC-25 ATC-55 ATC-115
Item Description Part No. Qty. Part No. Qty. Part No. Qty.
1 Armature Hub 540-0907 1 540-0852 1 540-0863 1
2 Retaining Ring 748-0732 1 748-0726 1 748-0737 1
3 Retaining Ring 748-0731 1 748-0728 1 748-0736 1
4 Bearing 166-0278 2 166-0277 2 166-0279 2
5 Spacer 807-0119 1 807-1061 1 807-1063 1
6 Splined Hub 1 1 1
1/2" Bore 540-0910
5/8" Bore 540-0911
3/4" Bore 540-0912 540-1501
7/8" Bore 540-0913 540-1502
1" Bore 540-1503
1-1/8" Bore 540-1504 540-0857
1-1/4" Bore 540-0858
1-3/8" Bore 540-0859
1-1/2" Bore 540-0860
*7-1 Armature 110-0220 1 110-0218 1 110-0223 1
*7-2 Screw 797-1519 4 797-1462 6 797-1463 6
*7-3 Lockwasher 950-0436 4 950-0355 6 950-0355 6
*7-4 Flatwasher 950-0023 2 950-0023 2
*8 Rotor 5161-751-001 1 5162-751-001 1 5163-751-001 1
8-1 Facing Assembly 5161-445-003 1 5162-445-003 1 5163-445-003 1
8-2 Retainer Plate 686-0108 1
8-3 Detent Ring 748-2031 1 748-2038 1 748-2020 1
8-4 Wave Spring 808-0404 1 808-0401 1 808-0384 2
8-5 Machine Screw 797-1389 8 797-1389 8 797-1389 8
*9 Bearing 166-0283 1 166-0284 1 166-0279 1
10 Field Assembly 1 1 1
6 volts DC 5161-451-002 5162-451-002 5163-451-002
90 volts DC 5161-451-003 5162-451-003 5163-451-003
24 volts DC 5161-451-004 5162-451-004 5163-451-004
*11 Retainer Ring 748-0018 1 748-0727 1 748-0737 1
12 Adapter 104-0300 2
13 Screw 797-1396 4
14 Lockwasher 950-0102 4
Optional Accessory Items
15
Conduit box 100-1 5162-101-002 1 5162-101-002 1 5162-101-002 1
16 Restraining Arm Assembly 5162-101-004 1 5162-101-004 1 5163-101-004 1
Kit Items
* Clutch Rebuild Kit 5161-101-011 1 5162-101-011 1 5163-101-011 1
(includes items 7-1, 7-2, 7-3, 7-4, 8, 9, 11)
Note: In some versions of this product, item 8 consists of a one (1) piece rotor.
Friction Face Replacement Kit
5161-101-007 5162-101-007 5163-101-007
For Clutches with Replaceable Friction Face Only
Mounting Accessory Kits (not shown)
1
1/2” Bore - 3/4” Bore 5161-101-001
1-1 Ring Retainer Ext. 748-0734 1
1-2 Wire Retainer 742-0027 1
1-3 Key 590-0104 1
1-4 Setscrew 797-1393 2
1 7/8’ Bore 5161-101-002
1-1 Ring Retainer Ext. 748-0734 1
1-2 Wire Retainer 742-0027 1
1-3 Key 590-0104 1
1-4 Collar and Setscrew 266-0031 1
1 3/4’ Bore - 1” Bore 5162-101-001
1-1 Ring Retainer Ext. 748-0725 1
1-2 Wire Retainer 742-0026 1
1-3 Key 590-0103 1
1-4 Setscrew 797-1386 2
1 1-1/8’ Bore 5162-101-010
1-1 Ring Retainer Ext. 748-0725 1
1-2 Wire Retainer 742-0026 1
1-3 Key 590-0103 1
1-4 Setscrew 797-1077 2
1-5 Collar 266-0032 1
1 All bore sizes 5163-101-001
1-1 Ring Retainer Ext. 748-0738 1
1-2 Wire Retainer 742-0026 1
1-3 Key 590-0105 1
1-4 Setscrew 797-1395
11 Warner Electric • 800-825-9050 819-0324
