4.0 DIAGNOSTICS, VERIFICATION, AND TROUBLESHOOTING
4.1 Performing an H and X Cable Diagnostic Test
Use the steps below to perform a diagnostic test on the H and X cables:
a. Start from the “START-UP” menu:
Press the [4] key (DIAG).
b. The following screen will be displayed:
Press the [1] key (CABLE TEST).
c. The following screen will be displayed:
Connect the H and X cables per the on-screen instructions and press the [ENTER] key.
d. The following screen will be displayed while the cables are being tested:
The screen will be updated with the status of each test as shown:
NOTE
“NOT OK” will be displayed for a failed diagnostic test.
Press any key to return to the “START-UP” menu.
