ATRT-03, ATRT-03A, AND ATRT-03B USER’S MANUAL REV 7
35
The test results will be displayed on the LCD screen when testing has finished:
The polarity is displayed as either a plus sign (+) for “in-phase” or a minus sign (-) for
“out-of-phase”. The value listed under “% DIFF” is the percentage error.
NOTE
The percentage error (% DIFF) is calculated as the absolute value of:
[(Calculated Ratio – Measured Ratio) / Calculated Ratio)] x 100
Press any key to continue.
If using an ATRT-03 or ATRT-03A, continue to step f.
If using an ATRT-03B, continue to step h.
f. The following screen will be displayed:
Press the [1] key (YES) to print the test results.
g. The following screen will be displayed:
Press the [1] key (COLUMN) to print a columnar report (see Figure 16) or press the [2]
key (DETAILED) to print a detailed report (see Figure 17).
h. The following screen will be displayed:
Press the [1] key (YES) to save the reading.
KEEP THIS READING?
1.YES
2.NO
PRINT FORMAT?
1.COLUMN
2.DETAILED
PRINT TEST RESULTS?
1.YES
2.NO
RATIO mA % DIFF
+10.009 0005 0.09
