ATRT-03, ATRT-03A, AND ATRT-03B USER’S MANUAL
REV 7
49
Press the
[ENTER]
key.
The following screen will be displayed:
Type the X winding name plate voltage value using the numeric keypad. The
screen will be updated as shown below:
Press the
[ENTER]
key. Continue to step e.
2. NO
Press the
[2]
key (NO) if you do not want to enter the transformer name plate
voltage values. Continue to step e.
e. The following screen will be displayed:
NOTE
This screen and subsequent screens will differ depending on the transformer
type selected. Follow any instructions displayed on the LCD screen.
Press the
[START]
key to run the test.
f. The following screen will be displayed temporarily:
The following screen will then be displayed:
Follow the instructions displayed on the LCD screen and then press the
[ENTER]
key.
JUMPER H1-H3
“ENTER” to CONTINUE
Dy11 XFMR
PLEASE WAIT...
Dy11 XFMR
JUMPER H2-H3
“START” to RUN TEST
ENTER X WINDING
NAME-PLATE VOLTAGE:
100 V
ENTER X WINDING
NAME-PLATE VOLTAGE:
V
