REV 2 Auto‐Ohm 200 S3 / DMOM‐200 S3 / DMOM‐600 USER’S MANUAL
3
The Auto‐Ohm‐200 S3 is furnished with a 30‐ft test (#1 AWG) cable set. A 15‐ft test cable set is
also available as an option. Test cables are terminated with heavy duty welding type clamps.
The test current and voltage sense cables are isolated and fastened to the clamp jaws. This
feature allows for a simple connection to the circuit breaker bushing. An optional voltage sense
cable and probe can be used to measure resist‐ance in small access locations. Optional
heavy‐duty, welding type C‐clamps are also available allowing the user to connect the test leads
to a wide variety of bushing sizes, bus‐bars, or large conductors.
