Tracer TP-9363 PRO-Chek CG AM08045-4 - Manual (Page 4)

4
PRO-Chek CG™ Features
• New, highly advanced thick film sensor
• Small sensor and probe tip allow leak checking in tight spaces
• Automatic adjustment (zeroing) to combustible gases in leak test area for
greater stability
• Innovative sensitivity touch pad for faster pinpointing of leaks
• Rugged flexible probe
• Variable audible signal as well as multiple LEDs to indicate leaks
Specifications
Sensitivity 5 PPM Methane (main component of
natural gas)
Power Supply Two D cell alkaline batteries
Battery Life Approximately 40 hours
Weight (with power cells) 1.5 lb (0.7 kg)
Product Warnings
To prevent ignition of a hazardous atmosphere, batteries must only be
changed in an area known to be nonhazardous (i.e., completely free
of combustible gas).
Use only Duracell ® MN1300 batteries to maintain intrinsically safe
approval.
Always check instrument operation with a known combustible leak
source before using.
The PRO-Chek CG will detect leaks as described below but may
not indicate when a hazardous atmosphere is present due to its
autozeroing function. Lack of a reading by the PRO-Chek CG should
not be taken as an indication that the atmosphere is totally safe.
There are no user serviceable parts inside. Do not disassemble the
PRO-Chek CG.
