AP033 Active Differential Probe
14 922260-00 Rev A
Table 2, Recommended oscilloscope settings to obtain desired equivalent Volts/Division
Equivalent
Scale Factor
Oscilloscope
Scale Factor
AP033
Attenuation
AP033
Gain
Common
Mode
Range
Differential
Mode
Range
Maximum
Offset
Input
Noise
(nV/√Hz)
100 μV/Div 1 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
200 μV/Div 2 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
500 μV/Div 5 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
1 mV/Div 10 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
2 mV/Div 20 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
5 mV/Div 50 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
10 mV/Div 100 mV/Div ÷1 X10 • ±4.2 V • ±40 mV • ±400 mV 6
20 mV/Div 20 mV/Div ÷10 X10 • ±42 V • ±400 mV • ±4 V 60
50 mV/Div 50 mV/Div ÷10 X10 • ±42 V • ±400 mV • ±4 V 60
100 mV/Div 100 mV/Div ÷10 X10 • ±42 V • ±400 mV • ±4 V 60
200 mV/Div 20 mV/Div ÷10 X1 • ±42 V • ±4 V • ±4 V 115
500 mV/Div 50 mV/Div ÷10 X1 • ±42 V • ±4 V • ±4 V 115
1 V/Div 100 mV/Div ÷10 X1 • ±42 V • ±4 V • ±4 V 115
2 V/Div 20 mV/Div ÷100
1
X1 • ±42 V • ±40 V • ±40 V 1150
5 V/Div 50 mV/Div ÷100
1
X1 • ±42 V • ±40 V • ±40 V 1150
10 V/Div 100 mV/Div ÷100
1
X1 • ±42 V • ±40 V • ±40 V 1150
1

÷100 attenuation obtained using the external ÷

attenuator. The probe is automatically set to

÷

internally when the
external attenuator is installed. The internal

÷

attenuator cannot be selected when the external ÷10 attenuator is installed.
Adding Offset
The AP033 has true differential offset capability. This allows you to remove a DC bias voltage from
the differential input signal while maintaining DC coupling. By using probe offset rather than the
“position” control on the oscilloscope, the full dynamic range of the probe remains centered
around the offset level.
