Example of interface list 3
The interface list below assumes that the third multi-point DIO board is installed in expansion slot 3
(I/O4).
I/O parameter No. 1 = “1” (Automatic assignment)
CN2 CN3 CN4
Category Pin No. Color
Port No.
Terminal name
Function
Port No.
Terminal name
Function
Port No.
Terminal name
Function
1 Brown-1
2 Red-1
COM terminal
For inputs
128 to 135
NPN: 24 V
PNP: 0 V
COM terminal
For inputs
144 to 151
NPN: 24 V
PNP: 0 V
COM terminal
For inputs
160 to 167
NPN: 24 V
PNP: 0 V
3 Orange-1 128 IN00 144 IN16 160 IN32
4 Yellow-1 129 IN01 145 IN17 161 IN33
5 Green-1 130 IN02 146 IN18 162 IN34
6 Blue-1 131 IN03 147 IN19 163 IN35
7 Purple-1 132 IN04 148 IN20 164 IN36
8 Gray-1 133 IN05 149 IN21 165 IN37
9 White-1 134 IN06 150 IN22 166 IN38
10 Black-1 135 IN07 151 IN23 167 IN39
11 Brown-2 136 IN08 152 IN24 168 IN40
12 Red-2 137 IN09 153 IN25 169 IN41
13 Orange-2 138 IN10 154 IN26 170 IN42
14 Yellow-2 139 IN11 155 IN27 171 IN43
15 Green-2 140 IN12 156 IN28 172 IN44
16 Blue-2 141 IN13 157 IN29 173 IN45
17 Purple-2 142 IN14 158 IN30 174 IN46
18 Gray-2 143 IN15 159 IN31 175 IN47
19 White-2
Input
20 Black-2
COM terminal
For inputs
136 to 143
NPN: 24 V
PNP: 0 V
COM terminal
For inputs
152 to 159
NPN: 24 V
PNP: 0 V
COM terminal
For inputs
168 to 175
NPN: 24 V
PNP: 0 V
21 Brown-3 +24 V +24 V +24 V
22 Red-3 0 V
For outputs
412 to 419
External
power input
0 V
For outputs
428 to 435
External
power input
0 V
For outputs
444 to 451
External
power input
23 Orange-3 412 OUT00 428 OUT16 444 OUT32
24 Yellow-3 413 OUT01 429 OUT17 445 OUT33
25 Green-3 414 OUT02 430 OUT18 446 OUT34
26 Blue-3 415 OUT03 431 OUT19 447 OUT35
27 Purple-3 416 OUT04 432 OUT20 448 OUT36
28 Gray-3 417 OUT05 433 OUT21 449 OUT37
29 White-3 418 OUT06 434 OUT22 450 OUT38
30 Black-3 419 OUT07 435 OUT23 451 OUT39
31 Brown-4 420 OUT08 436 OUT24 452 OUT40
32 Red-4 421 OUT09 437 OUT25 453 OUT41
33 Orange-4 422 OUT10 438 OUT26 454 OUT42
34 Yellow-4 423 OUT11 439 OUT27 455 OUT43
35 Green-4 424 OUT12 440 OUT28 456 OUT44
36 Blue-4 425 OUT13 441 OUT29 457 OUT45
37 Purple-4 426 OUT14 442 OUT30 458 OUT46
38 Gray-4 427 OUT15 443 OUT31 459 OUT47
39 White-4 +24 V +24 V +24 V
Output
40 Black-4 0 V
For outputs
420 to 427
External
power input
0 V
For outputs
436 to 443
External
power input
0 V
For outputs
452 to 459
External
power input
