INTELLIGENT ACTUATOR
4.2
IO24V Power Input
The power supply for IN000 to 023/OUT300 to 323 is insulated from the power supply for IN024 to
047/OUT324 to 347. Connect an external power supply for each power-supply terminal.
The power supply for IN024 to 047/OUT324 to 347 on the multi-point DIO board for K-Type
controller’s expansion slot is also connected to the IO24V power-supply connector on the controller’s
panel board.
This board also detects I/O power-supply errors through the following monitor functions:
1. Monitor the external I/O power-supply voltage (+24 V)
2. Monitor the output current for each 24-point group
