8.7 TF/TS Geared Trolley Parts for CB Hoist – 15 to 20 Ton
Figure
No.
Part Name
Parts Per
Trolley
15 Ton 20 Ton
1 Hand wheel Assembly
Geared
2 T3G123AM075
2 Slotted nut 2 T3G154050
3 Washer 2 9012515
4 Hand wheel 2 T3G123075
5 Split Pin 2 9009423
6 Snap ring 4 9047130
7 Ball bearing 4 9000506
8 Pinion 2 T3G127100
9 Socket bolt 8 9091272
10 Spring washer 8 9012711
11 Hand chain guide 4 T3G125075
12 Socket bolt 8 9091295
13 Spring washer 8 9012712
14 Pinion holder 2 T3G128100
15 Ball bearing 4 9000506
16 Snap ring 4 9047130
17 Hand chain 2 HCCF005
18 Side plate G Assembly 2 T3G5111075
19 Track wheel G Assembly 4 T3G1101075
20 Washer 8 MS104075
21 Snap ring 8 9047140
22 Snap ring 8 9047140
23 Washer 8 MS104075
24 Track wheel S assembly 4 T3G1102075
25 Side plate S assembly 2 T3G5110075
26 Name plate B 2 T3G801150 T3G801200
27 Suspension Shaft
Std.
2
MS115075
Wide MSF181075
28 Thick spacer*
Std. 6
MS117075
Wide 22
29 Thin spacer*
Std. 20**
MS116075
Wide 16
31 Bolt 2 MS161100
32 Shaft stopper pin 2 MS164075
33 Slotted nut 2 T3G154075
34 Split pin 2 9009436
35 Split pin 2 9009436
*See owner’s manual for placement of thick and thin spacers.
**For flange widths between 5 ½ to 5 , six (6) additional thin spacers are required (for a total of 26 thin
spacers).
