Harrington Hoists and Cranes GT Trolley User Manual
Page 12
2.2.2
PTS2 Dimensions
Table 2-6 PTS2 Trolley Dimensions
PTS2005 to PTS2030
PTS2050 to PTS100
Cap.
(Tons)
Product
Code
a
max
(in)
a'
(in)
b
(in)
e
(ft)
h
(in)
i
(in)
j
(in)
k
(in)
m
(in)
n
(in)
r
(in)
s
(in)
t
(in)
v
(in)
1/2
PTS2005
6.8
8.0
7.2
1.8
3.2
2.36
0.7
3.0
2.7
3.3
1.5
B-1.8
0.87
3.7
1
PTS2010
8.5
9.8
9.3
2.2
4.2
2.80
1.1
3.7
3.1
4.4
2.0
B-1.9
0.98
4.2
1 1/2-2
PTS2020
10.4
11.8
11.0
2.7
5.0
3.35
1.3
4.4
3.8
5.2
2.4
B-2.3
1.26
5.1
2 1/2-3
PTS2030
11.0
12.6
12.8
3.1
5.8
3.94
1.4
5.3
4.3
6.0
2.7
B-2.3
1.42
6.7
5
PTS2050
10.7
11.7
15.7
2.1
6.7
4.65
1.8
5.7
3.2
7.0
3.5
B-3.0
2.1
3.7
8
PTS080
14.4
19.2
19.4
4.1
7.3
6.10
-
6.7
5.9
7.7
6.0
B-3.6
2.76
4.7
10
PTS100
12
