8.2 TF2 Geared Trolley Parts – 1/8 to 5 Ton
Figure
No.
Part Name
Parts
Per
Trolley
1 Ton 2 Ton 3 Ton 5 Ton
1 Sideplate S Assembly 1 T6G5112010 T6G5112020 T6G5112030 T3P110050
2 Name plate B 1 T6G800010G T6G800020G T6G800030G T3G800050
3 Track wheel S Assembly 2 T6G5102010 T6G5102020 T6G5102030 T3P1102050
4 Track wheel washer 4 MS104010 MS104020 MS104030 MS104050
5 Snap ring 4 9047115 9047120 9047125 9047135
6 Track wheel G Assembly 2 T6G5101010 T6G5101020 T6G5101030 T3G1101050
7 Sideplate G Assembly 1 T6G5111010 T6G5111020 T6G5111030 T3G5111050
8 Pinion 1 T7GC121010 T7GB121020 T3G121020
9 Hand wheel 1 T6G123010 T3G123010
10 Washer 1 9012515
11 Split pin 1 9009423
12 Lever nut 1 L4082090 T3G259010
13 Bolt Assembly 1 T3P153050
14 Split pin 1 9009423
15 Slotted nut 1 T3P154050
16 Thin Spacer L 2 T6G119050
17a
Suspension shaft assembly
Standard
1 T7G1115010 T7G1115020 T7G1115030 T6G1115050
17 Suspension shaft 1 T7G115010 T7G115020 T7G115030 T6G115050
18 Thick spacer (qty) X T7G116010(6) T7G116020(6) T7G116030(9) MSF116050(3)
19 Thin spacer (qty) X T7G117010(9) T7G117020(8) T7G117030(11) T6G120050(8)
20 Shaft stopper pin 2 T6G156010 T6G156020 MS164020 MS164030
21 Split pin 2 9009423 9009432
22 Hand chain 1 HCCF005
23 Hand chain guide Assembly 1 T6G5121010
24 Suspender C 1 T7GC004010 T7GC004020
T7GC004030
(T7GCO04025)**
25 Suspender E 1 T7GB004010 T7GB004020 T7GB004030
26 Suspender H 1 T6G019010 T6G019020 T6G019030
27 TCR Suspender 1
60403 (1 Fall Chain)
6040201(2 Fall Chain)
6040403 TF26K531030S
28
Suspension Shaft Assembly
Extended
1
T7GD136010 {5.01 to
8.00”}
T7GD181010 {8.01 to
12.00”}
T7GD181020
{6.03 to 12.00”}
T7GD181030
{6.03 to 12.00”}
T6GD181050
{7.03 to 12.00”}
29 Suspension Shaft 1
T7GA0109136
{5.01 to 8.00”}
T7GA0109181
{8.01 to 12.00”}
T7GA0209181
{6.03 to 12.00”}
T7GA0309181
{6.03 to 12.00”}
T6GA0509181
{7.03 to 12.00”}
30 Thin Spacer X T7G117010 (10) T7G117020 (10) T7G117030 (10) T6G120050 (8)
31 Thick Spacer X
T7G116010
{5.01 to 8.00”}-(5)
{8.01 to 12.00”}-(7)
T7G116020 (11) T7G116030 (11) MSF116050 (11)
32 Bolt 1 T3P153050
33 Nut 1 T3P154050
34 Split Pin 1 9009423
35 Shaft Stopper Pin *2 T6G156010 T6G156020 MS164020 MS164030
36 Split Pin *2 9009423 9009432
37 Thin Spacer L 2 T6G119050
38 Fixing Spacer 2
T7GA0109137
{5.01 to 8.00”}
T7GA0109182
{8.01 to 12.00”}
T7GA0209182 T7GA0309182
39 Balancing Collar 2 T3GA0509137
* Quantity is 1 for 5 Ton.
** Suspender for use with model CB025, 2 ½ Ton.
