Table 5-5 Suspender Wear Measurements
Hoist Type
Trolley
Capacity
Hoist
Applied
Capacity
D
1
— D
2
Limit
d in. (mm) h in. (mm)
Standard Limit Standard Limit
CF or CB
1/2 1/2
0.04 (1)
0.48 (12.2) 0.512 (13.0)
0.551 (14.0) 0.492 (12.5)
1 1/2, 1 0.709 (18.0) 0.63 (16.0)
2 1 1/2, 2
0.64 (16.2)
0.669 (17.0)
0.866 (22.0) 0.787 (20.0)
3
2 1/2
0.06 (1.5)
1.063 (27.0) 0.945 (24.0)
3
0.646 (16.4)
0.945 (24.0) 0.846 (21.5)
5 5 1.299 (33.0) 1.181 (30.0)
Trolley Capacity D2 – D1 Limit
h d
Standard in.
(mm)
Limit in. (mm)
Standard in.
(mm)
Limit in. (mm)
1/2
0.04 (1)
0.40 (10) 0.33 (8.5) 0.48 (12.2)
0.51 (13)
1 0.51 (13) 0.45 (11.5) 0.49 (12.5)
2 0.75 (19) 0.67 (17)
0.80 (20.2) 0.83 (21)
3
0.06 (1.5)
0.87 (22) 0.79 (20)
5 – – 1.11 (28.2) 1.18 (30)
