9.6 Power Supply and Pendant Parts
Figure
No.
Part Name
Parts
Per
Hoist
001H 003S 003H 005L 005S
010L
/
020C
010S 015S 020L 020S 030C 025S 050L
1
Cord Support
(Wire Stop)
1 ER1BS9534
2
Mach. Screw
W/Spring
Washer 2 M6F554010
3
Socket Frame
Complete
Assembly
S
1
ER2CS4511 ER2ES4511
D ER2CI4511 ER2DI4511 ER2EI4511
4 Socket Frame 1 ER2CS9511
5
Socket 4P
Assembly S
1
ER2CS2523 ER2ES2523
D ER2CI2523 ER2CS2523 ER2EI2523
6
Tapping Flat
Head Mach.
Screw 8 ES558003
7
Socket 8P
Assembly S
1
ER2CS2564
D ER2CI2564 ER2EI2564
8
Mach. Screw
W/Spring
Washer
2 ES650005S
9
Mach. Screw
W/ Spring
Washer
6 MS561010
10
Socket Frame
Packing
1 ER2CS9512
11
Power Supply
Cable 4C
Assembly
1 ZBZA12CH1000 ZBZA12AH1000
12
Power Supply
Cable 4C
ft 16/4 14/4
13 Plug 4P 1 ECP2304AD ECP2304AF
14
Cable
Support Arm
1 ER1BS9541
15
Cable
Support 12
Assembly
1
ES822003
Cable
Support 14
Assembly
MS1724010
17
Cable Hanger
14 Assembly
A/R ES1527003
18
Pendant
W/Cord
Complete
Assembly
S
1
ZB10025H1000
D ZB20025I1000
19 Pendant Cord
S
ft
16/4P
D 16/6P
20
Pendent
Assembly
S
1
SWD1100AAH
D SWD2200AAH
21 Plug 8P
S
1
ECP2108AA
D ECP2108AB
22
Warning Tag
PB
1 WTAG7
23 Tag Holder 1 E3S787003
24
Machine
Screw
1 J1AP24002608
25 Nut 1 9093414
Note: A/R = As required, one every 5 ft. of Power Supply Cable.
