9.4 Electric Parts (Single Speed)
Figure
No.
Part Name
Parts
Per
Hoist
025S
050L
1
Limit Switch
Complete Assembly
1
ER2CI1060
2
Socket Bolt
3
9091247
3
Spring Lock Washer
3
9012709
4
Plate Assembly
1
ER2GHM20S5A2
5
Plate
1
ER2ES9441
6
Plate Screw
3
ER1BS9445
7
Transformer
1
TRF73V611
8
Electromagnetic
Contactor
1
MGC23406B
9
E-Stop Contactor*
1
MGC13306H*
MGC14306C*
10
Terminal Block 3P
1
ECP1303AB
11
Lead Wire
1
ER2GHM020S9A2
12
CH Meter
1
ECP91CHAE
13
CH Meter Support
1
ECP99BKBA
14
Rectifier
1
ECP94DIAA
15
Fuse
1
9006275
16
Fuse Holder
1
ECP92FZAA
17
Name Plate CH
1
ECP99CHAA
18
Terminal Block 6P
1
ECP1306AF
21
Machine Screw
2
9798512
22
Fulcrum Pin
1
ER2CS9449
23
Cover Suspender
1
ER2CS9456
24
Cover Belt
1
ER2CS9457
25
Socket Bolt
1
9091249
26
Plain Washer
1
ER1BS9436
27
Spring Lock Washer
1
9012709
28
Packing C
1
ER2FS9117
29
Balancer
1
ER2FS9109
30
Socket Bolt
3
9091273
31
Spring Lock Washer
3
9012711
32
Controller Cover
F
1
ER2FS9104
M
ER2FS2302
33
Name Plate B
1
ER2BHM25S9A5
34
Pan Head Mach.
Screw
2
9798534
35
Socket Bolt With
Spring Washer
4
J1BG10604040
36
Name Plate D
1
ER2BHM50R9A6
*Refer to the alpha-
numeric code on contactor. The code “S-N11” corresponds to
MGC13306
H. The code “CLK-25J3” corresponds to MGC14306C.
