9.3 Hook and Chain Parts
Figure
No.
Part Name
Parts
Per
Hoist
015S 020S 020L
1 Top Hook Assembly 1 ER2ES1001
2 Hook Latch 1 ER2ES1002
3 Suspender E (For Manual Trolley) 1 T7GB004020
4 Connection Yoke P (For Push Trolley) 1 ER2ES9027
5
Connection Yoke G
(For Geared Trolley)
1 ER2ES9029
6 Yoke Bolt 1 ER1ES9032
7 Slotted Nut 1 ES088020L
8 Split Pin 1 9009436
9 Suspender T 1 ER2ES9031
10 Top Pin 2 ER2ES9121
11 Plate A 1 ER2ES9123
12 Socket Bolt With Spring Washer 1 J1BG10601212
13 Shaft Clip 1 ER2ES9186
14 Chain Guide A 1 ER2ES9331
15 Chain Guide B 1 ER2ES9332
16 Socket Bolt 4 9091274
17 Spring Lock Washer 4 9012711
18 Machine Screw With Spring Washer 4 E6F151003
19 Guide Roller 1 ER1DL9333
20 Roller Pin 1 ER1DL9334
21 Limit Lever 1 ER2ES9337
22 Limit Lever Pin 1 ER2EL9338 ER2ES9338 ER2EL9338
23 Limit Lever Spring 1 ER2CS9357
24 Limiting Plate 1 ER1ES9054
25 Chain Spring 1 ER1DL9051 ES047015
26 Cushion Rubber 1 ER1ES9053
27 Cushion Rubber 1 ER1ES9053
28 Stopper Assembly 1 ER1ES1041
29 Bottom Hook Complete Assembly 1 ER2EM1011 ER2ES1011
30 Hook Latch 1 ER2EM1002 ER2ES1002
31
Plastic Chain Container Assembly
(Max. Lifting Height 13ft)
1 PBK2-E
32 Plastic Chain Container 1 ER2ES1401
33 Plastic Container Spring Assembly 1 ER2ES1416
34
Canvas Chain Container Assembly
(Max. Lifting Height 60ft)
1 BK2E2
35 Canvas Chain Container 1 ER2ES5405
36 Socket Bolt 1 90912107
37 Lever Nut 2 ES066075
38 Socket Bolt 1 90912104
39 NP Load Chain 1 LCER2020NP
40 End Suspender Kit 1 ENDS2E
41 End Suspender 1 ER2ES9408
42 Socket Bolt 1 90912107
43 Lever Nut 1 ES066075
44 Socket Bolt 1 90912152
45 Lever Nut 1 ES857005S
