61
9.3 Optional Parts
Figure 9-7 Top Hook Extender
Top Hook Extender
Fig. No. Name
Parts
Per
Hoist
¾ Ton 1 Ton 1 ½ Ton 2 Ton 2 ¾ Ton 3 Ton
1 Top Hook Extender 1 6073001 6073002 6073003 6073004 6073005 6073006
2 Bottom Hook Assembly 1 L5BU0081021 L5BU0101021 L5BU0151021 L5BU0201021 L5BU0281021 L5BU0301021
3 Latch Assembly 1 L5BA0081071 L5BA0101071 L5BA0161071 L5BA0251071 L5BA0321071
4 Chain Pin 1 L4041008 M3041015 L5BA0259041 L4BH0309041
5 Slotted Nut 1 M3049005 M3049010 M2049020 M2049020
6 Split Pin 1 9009402 9009411 9009412
7 Load Chain FT LCL5010NP LCL5015NP LCL5028NP LCL5030NP
8 Extension Block 1 60738 60735 60736 60737
9 Top Yoke Kit 1 TYKITL5008 TYKITL5015 TYKITL5028 TYKITL5030
10 Bottom Yoke Kit 1 BYKITL5008 BYKITL5015 BYKITL5028 BYKITL5030
11 Button Head Screw 6 9012601 9012602
12 Flexloc ® Nut 6 9012603 9012604
