If the show being displayed is a LaserDisk show, the display is altered slightly as shown:
- MACs SMART BRICK BRAIN - rev 1.05 copyright 1991-1992 GILDERFLUKE & Co. DCM -
a) show- 01 | g) next show- 02
b) time code- LaserDisk | h) immed.- no
c) brick- 00000 to 16384 | i) delay- yes
d) LaserDisk start- 12345 |
e) start string- 1 | m) more...
f) end string- 2 | X) exit
_01_|_02_|_03_|_04_|_05_|_06_|_07_|_08_|_09_|_10_|_11_|_12_|
O) string 1 - 01 | 50 | 4C | 0D |(52)|(0D)| 00 | 00 | 00 | 00 | 00 | 00 |
P) string 2 - 52 | 4A | 0D |(52)|(0D)| 00 | 00 | 00 | 00 | 00 | 00 | 00 |
Q) string 3 - 01 | 3A |(0A)| 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
R) string 4 - 4F |(0A)| 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
S) string 5 - 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
T) string 6 - 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
U) string 7 - 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
V) string 8 - 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
W) string 9 - 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 | 00 |
enter command-
¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥
ÒaÓ
Show Number:
This command is used to select which show you want to set up. As there are 63 possible shows, valid
entries are from 01H to 3FH. With most shows, all selections are through HEXadecimal numbers through
the 1/4 J-6 and serial ports, and for this reason you must use HEX numbers when selecting shows to con-
figure. Valid entries are:
01, 02, 03, 04, 05, 06, 07, 08, 09, 0A, 0B, 0C, 0D, 0E, 0F
10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 1A, 1B, 1C, 1D, 1E, 1F
20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 2A, 2B, 2C, 2D, 2E, 2F
30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 3A, 3B, 3C, 3D, 3Eh, 3Fh
When configuring SMPTE shows, the hour byte is used to select the shows. Since these actually come
from the SMPTE ÔhoursÕ, and this is a BCD number, valid show numbers for SMPTE shows are:
01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11, 12, 13, 14, 15, 16
17, 18, 19, 20, 21, 22, 23, and 24
Note that show number 24 is actually selected when the Brick Brain gets a SMPTE ÔhourÕ of 00. any
changes you have made in the current showÕs configuration will be written into the EEprom when you
select a new show number.
¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥
ÒbÓ
Time Code:
This command toggles through the four possible time codes:
LaserDisk
SMPTE
Internal time base
External time base
