frame of time code is received.
EXAMPLE: to set all of the Smart Bricks on Brick Brain 00 to address 1234:=
= 0 0 1 2 3 4
¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥¥
Т`У
Advance One Frame:
Т~У
Go Back One Frame:
These commands are uses as a test feature or to do a little single step programming. The first will ad-
vance the frame counters by 1 frame, while the second will subtract 1 frame from the current frame
count. Be aware that the minutes, seconds and frame counters may not be incremented properly, and
definitely wonÕt be decremented at all. A Smart Brick will only accept and remember data while stepping
forward into a new frame.
