ASCII Characters to be Received:
If you need to get a response from the serial port, you simply enter the character with bit seven set.
These characters will be displayed on the menu with parentheses around them and bit seven hidden to
show that they are response characters rather than ones which will be sent. The first character is a spe-
cial character unique to the Smart Brick System. Response ASCII characters translate into HEX as follows:
RESPONSE RESPONSE RESPONSE RESPONSE
ASCII HEX ASCII HEX ASCII HEX ASCII HEX
donÕt care 80 DLE 90 SPACE A0 0 B0
SOH 81 DC1 91 ! A1 1 B1
STX 82 DC2 92 Ò A2 2 B2
ETX 83 DC3 93 # A3 3 B3
EOT 84 DC4 94 $ A4 4 B4
ENG 85 NAK 95 % A5 5 B5
ACK 86 SYN 96 & A6 6 B6
BELL 87 ETB 97 Ô A7 7 B7
BS 88 CAN 98 ( A8 8 B8
HT 89 EM 99 ) A9 9 B9
LF 8A SUB 9A * AA : BA
VT 8B ESC 9B + AB ; BB
FF 8C FS 9C , AC < BC
C R 8D GS 9D - AD = BD
SO 8E RS 9E . AE > BE
SI 8F VS 9F / AF ? BF
RESPONSE RESPONSE RESPONSE RESPONSE
ASCII HEX ASCII HEX ASCII HEX ASCII HEX
@ C0 P D0 ` E0 p F0
A C1 Q D1 a E1 q F1
B C2 R D2 b E2 r F2
C C3 S D3 c E3 s F3
D C4 T D4 d E4 t F4
E C5 U D5 e E5 u F5
F C6 V D6 f E6 v F6
G C7 W D7 g E7 w F7
H C8 X D8 h E8 x F8
I C9 Y D9 i E9 y F9
J CA Z DA j EA z FA
K CB [ DB k EB { FB
L C C \ DC l EC | FC
M CD ] DD m ED } FD
N CE ^ DE n EE ~ FE
O CF _ DF o EF del FF
