Sonnet Technologies Encore_ZIF 1.0 GHz Processor Upgrade - Manual (Page 8)

3. Rotate and carefully lower the internal assembly back into the
computer’s case (Figure 17), making sure that no wires or
cables get pinched or crushed.
4. Slide and lock the internal assembly latches back into their
original position, and flip the support foot back into the case
(Figure 18).
5. Rotate and snap the expansion card cover back into place
(Figure 19).
6. Replace the case cover onto your computer.
7. Affix the Powered by Sonnet label to the front of your computer.
8. Return the computer to your computing area and reconnect the
power and peripheral cables to the computer.
Turn On Computer
1. Turn on your Power Macintosh; your accelerated machine
should boot normally.
2. If your system is running Mac OS 8.6, 9.1.x or 9.2.x, your instal-
lation is complete. If your system is running Mac OS 9.0.x, or Mac
OS X (any version), see page 24, “Installing Additional Software”.
Hardware Installation—G3 Desktop
Figure 17
Figure 18
Figure 19
expansion card
cover
latch
latch
internal assembly
support foot
