Hardware Installation—G3 Blue & White, G4 PCI Graphics

Figure 81

Figure 82

adapter cable

side panel

Close Computer

1. Arrange the wires and cables inside the computer so that noth-

ing will be pinched when you close the side panel

(Figure 81).

2. Raise the side panel back into place, making sure it latches

securely

(Figure 82).

3. Affix the Powered by Sonnet label to the front of your computer.

4. Return the computer to your computing area and reconnect the

power and peripheral cables to the computer.

Turn On Computer

1. Turn on your Power Macintosh; your accelerated machine

should boot normally.

2. If your system is running Mac OS 8.6, 9.1.x or 9.2.x, your instal-

lation is complete. If your system is running Mac OS 9.0.x, or Mac
OS X (any version), see page 24, “Installing Additional Software”.
