Salamander Designs FX200AV/L/BK User Manual
Fx200 panel mount assembly instructions, Parts

Salamander Designs Ltd.
www.salamanderdesigns.com
800-535-5659
©2005 Salamander Designs Ltd.
Doc No. 501-400 / v10.09 / 1 of 5
FX200 Panel Mount Assembly Instructions
PARTS
D
(4x) 301-705
M8 x 20mm Phillips Head
H
(4x) 301-700
M8 x 30mm Phillips Head
I
(4x) 301-710
M6 x 20mm Phillips Head
J
(4x) 301-715
M5 x 20mm Phillips Head
K
(4x) 301-720
M4 x 20mm Phillips Head
M
(4x) 301-730
Lag Bolt
N
(4x) 300-470
Flat Metal Washer
E
(4x) 301-460
M8 Bonded Washer
L (
4x) 300-515
1/4” Bonded Washer
F
(10x) 300-485
Button Head Screw
A
(2x)
301-400
Vertical Bracket
G
(1x) 400-080
5/32” Hex Key
FX200 Mount Hardware Bag - PHK-700
(3x) 400-010
Cable Ties
O
(4x) 300-560
Flat Nut
B
(1x)
301-920
Interface Bracket
C
(1x)
Tilt: 301-910 Fixed: 301-900
Wall Bracket
Alternate Fasteners - Be sure to utilize the matching washers with the enclosed screws. (Use screws E, I and J with washer F and
screws K and L with washer M.)
