Salamander Designs CA/BF2/4/E User Manual
Low profile & tapered wood, Foot
LOW PROFILE
& TAPERED
WOOD
FOOT
TIP: Level cabinet prior to loading with
equipment.
Doc No. 500-422/v11.10 ©2010 Salamander Designs Ltd.
FOOT PLACEMENT
CHAMELEON
SINGLES
TWINS
TRIPLES
QUADS
Leveler
ATTACHING FOOT
Use outer holes closest to
corner.
A. Slide connector bolt through wood feet and into
cabinet. Secure foot in place using hex key.
B. Fasten posts not requiring feet with provided
connector bolts.
C. Level cabinet as needed with plastic levelers.
CAMELEON CABINET
