Salamander Designs SN/PM/A - Manual

Salamander Designs Ltd. www.salamanderdesigns.com 800-535-5659
© 2012 Salamander Designs Ltd. Doc No. 500-885 / v10.12 / 1 of 5
Synergy Twin Panel Mount - SN/PM
I (4x) 301-705
M8 x 20mm Phillips Head
K (4x) 301-700
M8 x 30mm Phillips Head
L (4x) 301-710
M6 x 20mm Phillips Head
M (4x) 301-715
M5 x 20mm Phillips Head
N (4x) 301-720
M4 x 20mm Phillips Head
J
(4x) 301-460
M8 Bonded Washer
O ( 4x) 300-515
1/4” Bonded Washer
Synergy Twin Mount Hardware Bag - PHK-513
Alternate Fasteners - Be sure to utilize the matching washers with the enclosed screws. (Use screws I, J and K with washer L
and
Parts
D (1x) 301-422
Base Plate
E (1x) 3” Square Extruded Post
F (5x) 301-600
Wire Manager
A
(2x) 301-400
Vertical Bracket
B (1x) 301-406
Interface Bracket
C (1x) 301-416
Post Bracket
G (1x) 300-555
2” Button Head
H
(1x) 300-470
Metal Washer
V (1x) 400-080 5/32” Hex Key
U (1x) 400-060 3/16” Hex Key
W (1x) 400-070 1/8” Hex Key
T (1x) 301-425
Post Cover
S (4x) 301-575
Plastic Fasteners
R (8x) 300-560
Flat Nut
Q (14x) 300-485
Button Head Screw
