IMPORTANT SAFETY INFORMATION

WARNING:

■ Always turn off power at the main power source by unscrewing fuse or switching circuit breaker to the off position

before installing, removing, or cleaning this thermostat.

■ Read all of the information in this manual before programming this thermostat.
■ This is a 24V AC low-voltage thermostat. Do not install on voltages higher than 30V AC.
■ All wiring must conform to local and national building and electrical codes and ordinances.
■ Do not short (jumper) across terminals on the gas valve or at the system control to test installation. This will

damage the thermostat and void the warranty.

■ Do not switch system to cool if the temperature is below 50°F (10°C). This can damage the cooling system and

may cause personal injury.

■ The thermostat will not control your heating/cooling system without power. It requires four charged “AA” Energizer

brand batteries or equivalent alkaline batteries for thermostat operation, and a continuous 24V AC circuit for proper
system control.

■ Replace batteries every year or when “LO BATT” indicator appears on the thermostat display.
■ Use this thermostat only as described in this manual.

Symptom

Remedy

Thermostat beeps and does not allow

Autochangeover "deadband" conflict (See "SELECTING AUTO

temperature changes when

∨ or ∧

CHANGEOVER".) or thermostat is locked.

buttons are pressed.

Thermostat does not follow program.

Check AM/PM indicators at time of day and programmed time changes.
(See “PROGRAMMING.”)

Thermostat may be in "Early Recovery" mode. Check dip switch settings.
(See "PROGRAMMING" and "CHANGING DIP SWITCH SETTINGS").

Thermostat may be OFF. Select HEAT or COOL mode by pressing SYSTEM
button.

Program may not have been done in HEAT or COOL modes.
(See "PROGRAMMING".)

Both HEAT and COOL programs utilize the same setpoint time and
programmable fan settings. Only setpoint temperatures can be different.
(See "PROGRAMMING".)

Check compatibility guide and system specifications.

Thermostat in MANUAL mode. (See “OPERATION.”)

Thermostat may not have been programmed in HEAT or COOL position.
Verify program. (See “PROGRAMMING – To Review or Change Program.”)
