TYPICAL RESIDENTIAL SCHEDULE (300-224, 300-226, 300-230)
30
Temperature Settings
Weekday Time
AM/PM
Weekend Time
AM/PM
MORNING
HEAT
68
COOL
72
6:00 AM
8:00 AM
DAY
HEAT
64
COOL
85
9:00 AM
8:00 AM
EVENING
HEAT
68
COOL
72
3:30 PM
8:00 AM
NIGHT
HEAT
62
COOL
78
10:30 PM
10:30 PM
0
2
1
©©
The first thing to do before programming your thermostat is to determine your personal comfort
levels for each day with respect to time of day and desired temperature. A typical schedule is
shown above.
On weekdays, after the temperature has been lowered all night, the thermostat can be pro-
grammed to begin warming the house at 6:00 AM, if the household gets up at 7:00 AM. At 9:00
AM, after everyone has left for the day, the thermostat can be set to lower the temperature to
save energy during the day. Before anyone arrives home in the afternoon, the temperature may
again be increased to provide comfort for when the household returns. Finally, at bedtime, the
thermostat again lowers the temperature to save energy during the night.
On Saturday and Sunday when everyone is home, the temperature comes up to 68°F at 8:00
AM and stays there all day until 10:30 PM when the temperature sets back to 62°F.
