MicroPak - Operation
Ransburg
24 LN-9218-00.13
HV On Command
HV Reset
Fluid Trigger / Di/dt Delay
Air Trigger
HV On Command
HV Reset
Fluid Trigger / Di/dt Delay
Air Trigger
HV On Command
HV Reset
Fluid Trigger / Di/dt Delay
Air Trigger
HV On Command
HV Reset
Fluid Trigger / Di/dt Delay
Air Trigger MicroPak #1
MicroPak #1
MicroPak #1
MicroPak #1
MicroPak #2
MicroPak #2
MicroPak #2
MicroPak #2
MicroPak #3
MicroPak #3
MicroPak #3
MicroPak #3
MicroPak #4
MicroPak #4
MicroPak #4
MicroPak #4
Bit Module
1/00
1/01
1/02
1/03
1/04
1/05
1/06
1/07
1/10
1/11
1/12
1/13
1/14
1/15
1/16
1/17
DISCRETE OUTPUT BIT DEFINITION
Output
BTW Word Module
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
MicroPak #1
MicroPak #1
MicroPak #1
(Not Used)
MicroPak #2
MicroPak #2
MicroPak #2
(Not Used)
MicroPak #3
MicroPak #3
MicroPak #3
(Not Used)
MicroPak #4
MicroPak #4
MicroPak #4
(Not Used)
High Voltage Setpoint (Value of 0 - 100 corresponds to 0 - 100 kV)
Current Limit Setpoint (Value of 0 - 250 corresponds to 0 - 250 µA *)
Di/dt Setpoint ( 0 - 9 corresponds to max. to min. sensitivity)
----
High Voltage Setpoint (Value of 0 - 100 corresponds to 0 - 100 kV)
Current Limit Setpoint (Value of 0 - 250 corresponds to 0 - 250 µA *)
Di/dt Setpoint ( 0 - 9 corresponds to max. to min. sensitivity)
----
High Voltage Setpoint (Value of 0 - 100 corresponds to 0 - 100 kV)
Current Limit Setpoint (Value of 0 - 250 corresponds to 0 - 250 µA *)
Di/dt Setpoint ( 0 - 9 corresponds to max. to min. sensitivity)
----
High Voltage Setpoint (Value of 0 - 100 corresponds to 0 - 100 kV)
Current Limit Setpoint (Value of 0 - 250 corresponds to 0 - 250 µA*)
Di/dt Setpoint ( 0 - 9 corresponds to max. to min. sensitivity)
----
BLOCK TRANSFER WRITES
BTW Block Configuration
MICROPAK NODE ADAPTER PLC I/O
(Cont.)
- MicroPak Mode
* 0-85 corresponds to 0-85 µA for HP404 FM
0-1000 corresponds to 0-1000 µA for RP1000 or LEPS5002 applications.
