Aerbell 33 Rotary Atomizer - Parts Identification
Ransburg
45 LN-9521-00.4
Install fitting hand-tight, then 1/4 turn with wrench.
Apply 59915-01 tape to all male pipe threads.
* PARTS LIST BULLET DEFINITION TABLE (Figure 19)
* See "Parts List Bullet Definition Table" below.
Item #
WATERBORNE FLUID MANIFOLD ASSEMBLY -
PARTS LIST (Figure 19)
Part # Description
Qty
Notes*
1
2
2A
3
3A
4
4A
5
AER0068-00
LSFI0022-04
LSMM0035-03
LSFI0022-07
LSMM0035-05
76917-00
AER4018-00
LSFI0013-03
Manifold, Fluid, Engraved
Fitting, 1/4 O.D. Tube x 1/4 AN Union
Plug, Protective, 1/4 AN
Fitting, 3/8 O.D. Tube x 3/8 AN Union
Plug, Protective, 3/8 AN
Valve Assembly, Cartridge, HV
Plug Assembly, Valve Port
Fitting, 1/4 O.D. Tube x 1/8 NPT
AER4020-00 AER4021-00 AER4022-00 AER4023-00
1
----
2
----
2
1
2
1
1
----
2
2
----
2
1
2
1
2
----
----
2
2
1
2
1
2
----
2
----
3
----
3
2
2
1
2
1
