Ransburg Aerobell 33 AER5000, AER5001 - Manual (Page 12)

Aerbell 33 Rotary Atomizer - Introduction
Ransburg
8 LN-9521-00.4
SPECIFICATIONS
Power Supply LECU5003 /LEPS5001
Type: (Voltage Master TM )
76045 / LEPS5002
(MicroPak TM )
Charging Method: Direct
Output Voltage: 30-100 kV Variable
Output Current: 125 µA (Short Circuit)
Turbine Speed
Control: PulseTrack or Eurocard
Atomizer Module
Paint Resistance:* .1 MΩ to ∞
*(Use Model No. 76652, Test Equipment)
Part Sprayability: Determine sprayability
of part to be coated
using 76652, Test
Equipment
(See TE-98-01).
Electrical
Bearing Air Supply: (See Figure 6)
(Nominal) 90 psig (±10 psi)
(621 kPa ±69 kPa)
2.1 scfm (60 slpm)
Shaping Air Supply: Variable (See Figure 5)
( Nominal) 5-15 psig (34-103 kPa)
4.7-9.8 scfm (134-280
slpm)
Brake Air Supply: 60 psig (414 kPa)
(Nominal)
Maximum Fluid
Pressure Supply: 100 psig (689 kPa)
Fluid Flow Rate: 25-500 cc/minute
Usable Spray
Pattern Diameter: 15-30 inches (381-762 mm)
Bell Cup
Cleaning Time: Approximately 2-3 sec.
Color Change Time: Dependent on system
configuration, fluid
pressure, fluid viscosity,
fluid line lengths, etc.
Speed Readout: Magnetic pickup,
unidirectional fiber-optic
transmission
Atomizer
Replacement Time: Less than 2 minutes
Bell Cup
Replacement Time: Less than 2 minutes
Mechanical
Length: 16.5 inches (419mm)
Diameter: 5.6 inches (142mm)
Approximate
Weight: 10.3 lbs. (4.7 kg)
Turbine Type: Air Bearing Impulse Drive
Turbine Air Supply: Variable (See Figures 1-4)
At 30,000 rpm 23 psig (158 kPa)
(Nominal): 7.7 scfm (220 slpm)
Maximum Turbine
Speed: Continuous (Intermittent)
30mm Bell Cup: 40,000 rpm (55,000 rpm)
57mm Bell Cup: 40,000 rpm (55,000 rpm)
Mechanical (Cont.)
