Ransburg Aerobell 33 AER5000, AER5001 - Manual (Page 14)

Aerbell 33 Rotary Atomizer - Installation
Ransburg
10 LN-9521-00.4
INSTALLATION
AIR FILTER INSTALLATION
The following air filter installation guidelines are
essential for optimum performance.
1. Use only recommended pre-filters and bearing
air filters as shown in Figure 8. Additional system
air filtration (i.e., refrigerted air dryer) may also be
used if desired.
2. Mount the bearing air filter as close as possible
to the Aerobell 33. (Do not mount further than 30
feet away.)
3. Do not use tape, pipe dope, or other thread
sealant downstream of the bearing air filter. Loose
flakes of tape or other sealant can break loose
and plug the very fine air holes in the turbine air
bearings.
4. If air heaters are used in the system (to mini-
mize the effect of excessively humid conditions),
and the heated air will exceed 120°F, the heaters
must be located after all filters to prevent damage
to the filter media.
AIR PRESSURE
REQUIREMENTS
1/4" O.D.
1/4" O.D.
1/2" O.D.
3/8" O.D.
3/8" O.D.
1/4" O.D.
1/4" O.D.
1/4" O.D.
Bearing Air Supply
(B.A)
Bearing Air Return
(B.A)
Turbine Air (T.A)
Shaping Air (S.A)
Brake Air (BRK)
(if used)
Trigger Valve
Control (TV)
Dump Valve
Control (DV)
Solvent Valve
Control (SV)
90 psi ±10
(621kPa ± 69kPa)
80 psi ±10
(551kPa ± 69kPa)
Variable
Variable
60 psi ±10
(413kPa ± 69kPa)
80 psi ±10
(551kPa ± 69kPa)
80 psi ±10
(551kPa ± 69kPa)
80 psi ±10
(551kPa ± 69kPa)
Figure 7: Air Tubing Connections
Tube
Size
Air Pressure
Requirements
Paint Fluid Regulator (Optional):
High Flow
Signal Air (High)
Low Flow
Signal Air (Low)
1/4" O.D.
1/4" O.D.
Variable
70 psi max. (482
kPa)
Variable
80 psi max. (551
kPa)
