Aerbell 33 Rotary Atomizer - Maintenance
Ransburg
31 LN-9521-00.4
† Care should be taken to not over tighten
the fluid tube and strip the threads.
When installing a new or old feed tube, once
it is securely tightened, check the position of
the feed tube in the shaft at the front of the
assembly. If the feed tube is off center by
more than .020-.028 radially, replace it with
another feed tube. If the feed tube protrudes
out of the shaft a distance other than .207
(-.015 / +.030), replace the tube with another
feed tube.
C A U T I O N !
NOTES Speed Transducer Removal
To remove the speed transducer, follow the pro-
cedures for removal of the rear shroud. Then
loosen the compression nut on the transducer
body, and pull the fiber-optic cable out. Using an
11/16 open-end wrench, turn the speed transducer
CCW to disengage the threads completely, and
then pull the unit straight out of the air manifold.
Fluid Tube Removal
To remove the fluid tube assembly (Figure 16a,
item 3), follow the procedures for removing the
rear shroud and fluid manifold assembly. Once
the fluid manifold is removed, the fluid tube will
be exposed at the rear of the air manifold. Using
a standard 3/4 inch socket, engage the hexagon
flats on the feed tube, and turn CCW to loosen.
After disengaging the threads completely, pull the
feed tube straight out of the air manifold.
