Aerbell 33 Rotary Atomizer - Parts Identification
Ransburg
41 LN-9521-00.4
1 AER4005-00 Manifold, Air, Engraved 1
2 AER0026-00 Stud, Mounting 1
3 AER0022-00 Pin, Fiberglass 2
4 LSFI0013-01 Fitting, 1/2 O.D. Tube x 3/8 NPT 1
5 LSFI0013-02 Fitting, 3/8 O.D. Tube x 1/4 NPT 2
6 LSFI0013-04 Fitting, 1/4 O.D. Tube x 1/4 NPT 2
7 LSFI0023-02 Plug, 3/8 O.D. Tube Fitting 1
8 LSFI0024-03 Plug, 1/2-20 1
9 LSFI0025-22 Fitting, 3/8 O.D. Tube x 3/8 NPT 1
10 LSOR0005-02 O-Ring, Solvent Proof 1
11 AER0021-00 Rod, Rear Plate Support 3
12 AER0062-01 Plate, Rear 1
13 AER0027-00 Shroud, Rear 1
14 LSFA0001-16C Screw, 1/4-20 x 1/2 Long Nyl. Pan Head 3
15 AER0023-00 Fastener, Rear Cover 2
Do not use any lubricant; O-ring must remain dry.
Place rear shroud over assembly before securing rear plate.
Install rear cover fasteners below the surface of rear plate before installing the rear shroud. To lock
the shroud into position, align the mounting holes (with the fasteners) and rotate each fastener count-
er-clockwise until it fits snugly against the shroud.
Orient mounting stud with flat towards front, as shown.
Apply 59915-01 tape to all male pipe threads.
* PARTS LIST BULLET DEFINITION TABLE (Figure 17)
* See "Parts List Bullet Definition Table" below.
Item #
MANIFOLD ASSEMBLY - PARTS LIST (Figure 17)
Part # Description Qty Notes*
1
2
1
1
6
1
4
4
3
4
4
6
3
2
1
