Aerbell 33 Rotary Atomizer - Parts Identification
Ransburg
39 LN-9521-00.4
.300 dia. (Ref) of feed tube 76416-xx to be concentric to .500 I.D. (Ref) of shaft AER0032 (Ref) to within
.020-.028 radially; Use AER0076-01 (Ref) center checking gauge to check feed tube location.
Rebuild air motor/bearing using AER4019 kit (not included with this assembly).
Warning: Torque to 50 lb • in +40/-0 lb • in.
Tighten screws alternately to a final torque of 15 lb • in.
AER4014 support assembly is shown for reference only, is not included with this assembly and must be
ordered separately.
Must be connected between "P.OUT" on fluid regulator and "P.IN" on fluid manifold assembly.
** PARTS LIST BULLET DEFINITION TABLE (Figure 16)
* See corresponding table and column on pages 38 & 39
** See "Parts List Bullet Definition Table" on page 40
1 AER4004-01 Manifold Assembly, Air 1
2 See "J" (Table "A") Shaping Air Cap w/Shroud 1
3 See "K" (Table "B") Fluid Tube 1
4 79001-05 O-Ring, Solvent Proof 1
5 LSFA0014-00 Screw, Retaining 4
6 AER4013-00 Tube Assembly, High Voltage 1
6A 79001-05 O-Ring, Solvent Proof (Ref)
7 See "L" (Table "C") Manifold Assembly, Fluid 1
8 LSFA0006-16F Screw, #10-32 x 1/2 Long SST. Socket Head Cap 4
9 LSFA0004-56C Screw, 1/4-20 x 1-3/4 Long Nyl. Fill. Head 2
10 AER4006-00 Turbine Assembly, Air Bearing 1
7554-103 Turbine Assembly O-Ring, Solvent Resistant 1
7554-104 Turbine Assembly O-Ring, Solvent Resistant 1
11 7554-03 O-Ring, Solvent Resistant 1
12 RPM-2 Retainer, Shaping Air Cap 1
13 See "M" (Table "A") Ring, Shaping Air 1
14 55994-25 Tubing, 3/8 O.D. 2.75"
15 LSOR0005-01 O-Ring, Solvent Proof 1
16 See "N" (Table "A") Bell Cup Assembly 1
17 LSFI0022-04 Fitting, 1/4 O.D. Tube x 1/4 AN Union R*
18 See "T" (Table "D") Regulator Assembly, Fluid S*
19 --------------------------------- ----------------------------------------------------------------------- ----
20 AER0043-00 Cover, Connector, Machined V*
21 LSFA0007-12C Screw, #10-24 x 3/8 Long Nyl. Pan Head W*
22 See "X" (Table "E") Module, Voltage 1
22A 76419-00 Strain Relief, High Voltage Cable (Ref)
23 55994-25 Tubing, 3/8 O.D. 36"
24 AER0063-00 Cover, Rear Plate (Not Shown) Y*
25 LSFI0022-07 Fitting, 3/8 O.D. Tube x 3/8 AN Union RR*
26 LSFI0041-01 Elbow, 1/4 O.D. Tube x 1/8 NPT, Special Z*
27 55994-28 Tubing, 1/4 O.D. 7"
Item #
AEROBELL 33 - PARTS LIST (Figure 16)
Part # Description Qty Notes**
17
9
11
3
13 17
13
17
9
11
3
4
