Turbodisk Applicator - Parts Identification

68

* See corresponding column in Table "A"

1

Retainer, Bearing

70873-00

1

2

Screw, #6-32 x 3/8" Long, Hex Socket, Flat Head

78232-12C

12

3

Slinger

70876-00

1

4

Spacer, Bearing

20298-00

1

5

Bearing, Ball

70896-00

2

6

O-Ring, 1.614" ID, Solvent Resistant

7554-77

1

7

O-Ring, 3.489" ID, Solvent Resistant

7554-73

1

8

Decal, 20292-xx Turbodisk

73180-02

1

9

Key, Woodruff, 1/2" Dia.

8310-01

1

10

Nut, Self-Lock, 5/8-18, UNF

7729-10

1

11

Seat, Spring

20966-00

1

12

Spring, Compression

70868-00

1

13

Screw, Set, Special

70871-00

1

14

Housing, Bearing, Machined

70875-00

1

15

O-Ring, 2.239" ID, Solvent Resistant

7554-17

1

16

Plate, Nozzle

A*

1

17

Rotor, Turbine

B*

1

18

Shaft, Air Motor

C*

1

Item #

70879-XXX TURBODISK TURBINE CARTRIDGE ASSEMBLY -

PARTS LIST (Figure 19)

Part #

Description

Qty

Part #

Description

A

TABLE "A" (Figure 19)

B

70879-406

70879-456

Motor, Turbodisk, Clockwise Rotation

Motor, Turbodisk, Counter-Clockwise Rotation

C

20291-10

20291-60

20292-31

20292-32

70897-01

70897-02

9

6

7

8

8

** See "Parts List Bullet Definition Table"

Prime thread with P/N 7991-00 primer (Loctite 19267) and bond with P/N 7969-03 Loctite

(Blue 24077)

These denote magnetic/fiber optic assemblies.

Apply 7969-02 (Red 27121) Loctite to threads.

This o-ring to be assembled dry.

9

** PARTS LIST BULLET DEFINITION TABLE (Figure 18)

8

7

6
