background image

Turbodisk Applicator - Parts Identification

56

3

Use as required to increase fluid pressure at regulator outlet to approx. 5-20 psi
Pressue Change Across Tubing (PSI)

.601 X 10

6

X Flow Rate (mi/min) X Viscosity (Poise) X Fluid Length (in)

[Tube ID (in)]

4

Item #

70990-11 TURBODISK ASSEMBLY, DUAL DR-1 REGULATORS - PARTS LIST (Figure 13)

Part #

Description

Qty

Notes

1

70976-01

Feed Tube Kit, Downfeed

1 Part of 70988-XX Kit

2-1

8156-24F

Screw, 5/16-24 X 3/4", Hex Head

2

2-2

8156-32F

Screw, 5/16-24 X 1", Hex Head

5

2-3

8156-40F

Screw, 5/16-24 X 1-1/4", Heax Head

1

2-4

7734-07

L Washer, Spring, 5/16"

6

2-5

17274-00

High Voltage Connector Assembly

1

2-9

15980-00

Extension Arm, Air Motor

1

2-10

1613-03

Tube Support, 20-3/8"

1

2-11

8156-48F

Screw, 5/16-24 X 1-1/2", Hex Head (Not Used)

2

2-13

27141-081

Hose Wrapping (Not Shown)

25'

Same as TR-SSEM-082

2-14

15946-00

Grounding Hook Assembly (Not Shown)

1

2-15

10384-01

Tubing, Latex, 3/16" ID X 1/16" Wall (Not Shown)

50'

3-1

9704-03

Tubing, LD/PE, 1/4" OD X .17" ID

100'

3-2

7113-13

Tubing, 1/2" OD X .060" Wall, Nylon

50'

3-3

SSP-5020

Tubing, 3/8" OD X 1/4" ID

100' Supplied with Kit 70977-04

only

3-3

55994-26

Tubing, 1/2" OD X 3/8" ID 100' Supplied with Kit 70977-05

only

3-4

78006-00

Elbow, 3/8" OD Tube X 1/4" NPT 2 Supplied with Kit 70977-04

only

3-4

LSFI0005-01

Connector, Straight, 1/2" OD Tube X 1/4" NPT

4 Supplied with Kit 70977-05

only

3-5

41-FTC-1002

Connector, Straight, 3/8" OD Tube X 1/4" NPT

4

4-1

70590-01

Connector, Male, 1/4" OD Tube X 1/4" NPT, SS

2

4-2

76462-00

Tee, 1/4" NPT (X2) X 1/4" NPTM, SS

2

4-3

LSFI0038-00

Elbow, 1/4" NPTF X 1/8" NPTM, SS

2

4-4

LRPM0105

Bracket

2

4-5

CCV-12-SS

Valve Adapter

2

4-6

LDSK4000

2-Valve Assembly, Trigger and Dump

2

4-7

SSP-6054

Connector, 1/4" OD Tube X 1/8" NPT, Male, Brass

2

4-8

55994-28

Tubing, FEP, .188" ID X .250" OD

5'

4-9

SSP-1421

Plug, Hex Socket, 1/4" NPT

2

4-15

LSFI0007-01

Elbow, Male, SS

2

4-16

LSFI0006-01

Elbow, 1/4" OD Tube X 1/4" NPT,Female, SS

2

4-17

SSV-809

Check Valve, 1/4" NPT

2

4-19

SSF-8125

Hex Jam Nut

2

These parts are supplied with Kit 70977-04 (3/8" OD) Low Flow or 70977-05 (1/2" OD) High

Flow, Tube & Fitting Kit (Shipped loose as Kit, no assembly)

These parts are supplied with Kit 70973-01 Hardware & Mounting Parts Kit

These parts are supplied with Kit 70975-11 Trigger Valve Kit

(Continued On Next Page)

AA-07-02.1
