Turbodisk Applicator - Maintenance

22

Installation

Always check the inside of the motor housing and

clean, if required, with a minimum amount of an ap-

propriate cleaning solvent and a soft cloth.

1. Using a 1/16-inch Allen wrench, retract the three

(3) jack screws.

2. With o-rings in place on the nozzle plate and

housing, insert the turbine cartridge into motor

housing.

3. Secure the rotator assembly to the housing with

six socket head cap screws. Tighten the screws in

sequence until the cartridge is fully engaged into

the housing to prevent misalignment and possible

damage. Torque to 10 lbs•in.

5. With a 7/64-inch Allen wrench, remove six (6)

socket head cap screws, which secures the turbine

cartridge to the motor housing.

6. Using a 1/16-inch Allen wrench, turn each of the

three (3) jack screws, located next to socket head

cap screw, clockwise not more than one half turn at

a time in sequence to separate the motor from the

housing.

>

Lightly lubricate o-rings with petroleum

jelly before assembly. Fit parts with

o-rings very carefully. They must not be al-

lowed to distort, unseat or break.

C A U T I O N

!

>

Failure to perform this step correctly

may result in misalignment and possible

damage.

>

Use caution in removing cartridge to

prevent it from falling out of the housing.

C A U T I O N

!

>

Any attempt to disassemble turbine dur-

ing the warranty period will void the war-

ranty.

C A U T I O N

!

NOTES:

• Never use any silicone compound in this

system!

• Never use any lubrication on the bearings!

• Never use any solvent on the bearings!

• Never exert force on one race of a bearing

assembly that may be transmitted to the other

race through the bearings! Force and resist-

ance must always be on the same race in

order to prevent damage.

• Do not enlarge the nozzle passages during

cleaning, as it will effect performance.

• Always observe the specified torque in

tightening fasteners.

• Clean all parts thoroughly with an appropriate,

clean solvent. Inspect them for wear or damage

and replace as required.

• Check all flow passages for obstruction,

particularly the nozzle plate. Clear as required.

• Discard o-rings and replace with new. Lightly

lubricate o-rings with petroleum jelly before

assembly. Fit parts with o-rings very carefully.

They must not be allowed to distort, unseat, or

break.

>

Failure to observe the following cautions

will result in diminished performance and

premature motor failure.

C A U T I O N

!

4. To avoid losing the jack screws during normal

operation, torque to 2-3 lbs•in (0.23-0.34 Nm).

Turbine Cartridge Service

This cartridge is a precision instrument and should

be handled with care. The bearings are preloaded to

30 lbs. (13-6 Kg) and dynamically balanced.

Turbine bearing unit must be returned to Ransburg

for rebuilding.
