Turbodisk Applicator - Parts Identification

31

(1) Disk Mounting Nut (See "Table A") is included with this assembly. When mounting disk (not included),

torque mounting nut to 50-60 lbs•in (5.65-6.75 Nm). (Recommended: 3/8" hex bit socket with square drive

torque wrench.)

DR-1 Fluid Regulator, 74151-XX can only be used with Fluid Control Valve Kits 70975-09 and 70975-10 as

shown in "Table C".

General Application Guideline: Use DR-1 Regulator for paint flow rates from 25 to 1500 cc/min.

High Flow Fluid Regulator, 70171-04, can only be used with Fluid Control Valve Kits 70975-07 and

70975-08 as shown in "Table C".

General Application Guideline: Use High Flow Regulator for paint flow rates above 750 cc/min.

* PARTS LIST BULLET DEFINITION TABLE

9

7

6

Dash #

TABLE "E" - FIBER OPTIC PICKUP

Part #

0

1

--

SMC-29

Description

None

Fiber Optic Pickup

Dash #

TABLE "G" - DISK TYPE

Part #

00

01

02

03

04

05

06

07

08

09

10

--

20485-62

20485-65

20485-92

20485-95

20485-122

20485-125

19830-06

19830-08

19830-10

19830-12

Description

None

Disk Assy., Serrated, 6", Aluminum, Not Anodized

Disk Assy., Serrated, 6", Aluminum, Anodized

Disk Assy., Serrated, 9", Aluminum, Not Anodized

Disk Assy., Serrated, 9", Aluminum, Anodized

Disk Assy., Serrated, 12", Aluminum, Not Anodized

Disk Assy., Serrated, 12", Aluminum, Anodized

Uni-Disk Assy., 6", Aluminum, Not Anodized

Uni-Disk Assy., 8", Aluminum, Not Anodized

Uni-Disk Assy., 10", Aluminum, Not Anodized

Uni-Disk Assy., 12", Aluminum, Not Anodized

Dash #

TABLE "F" - AIR HEATER

Part #

0

1

2

--

78781-00

78170-00

Description

None

Air Heater Manifold Package With High Flow Regulator

Regulator Assembly - No Heater

AA-07-02.1
