Turbodisk Applicator - Parts Identification
PARTS IDENTIFICATION
29
A11376 TURBODISK ASSEMBLY MODEL IDENTIFICATION
Turbodisk Assemblies are available with the various options as follows:
Dash #
TABLE "A" - BASIC SYSTEMS KIT W/HIGH SPEED AIR MOTOR
Kit Part #
1
2
3
4
5
6
7
8
70988-01
70988-02
70988-03
70988-04
70988-05
70988-06
70988-07
70988-08
Mounting
Nut
19836-01
19836-02
19836-03
19836-04
19836-05
19836-06
19836-07
19836-08
Description
Downfeed Clockwise - No Tilt
Downfeed Counter-Clockwise - Not Tilt
Upfeed Clockwise - No Tilt
Upfeed Counter-Clockwise - No Tilt
Downfeed Clockwise - No Tilt
Downfeed Counter-Clockwise - No Tilt, Dual Feed Tube
Upfeed Clockwise - Not Tilt, Dual Feed Tube
Upfeed Counter-Clockwise - No Tilt, Dual Feed Tube
9
Model No. A11376 - X X X X X X XX
Basic Part Number
Part A - Basic Systems Kit With High Speed Air Motor
Part B - Fairing
Part C - Fluid Control Valve Kit
Part D - Paint Hose
Part E - Fiber Optic Pickup
Part F - Air Heater
Part G - Disk Type
