Turbodisk Applicator - Introduction

7

TYPICAL SPEED CHART

(RPM's)

(No Load)

(Refer to "Typical Speed Chart")

The following represents data collected under lab

conditions. Flow meters were installed on each of

the two 3/8-inch ID heated air lines used to supply

the Turbodisk turbine motor. The airflow through

each flow meter was recorded and added together

to obtain the total air flow through the system. The

speed of the disk was monitored through the means

of a PulseTrack system. The air heater was set at 120

degrees during all data collection.

Rotational speeds are unloaded and can be expected

to drop 20 to 30% when under a fluid load condition.

Heated turbine air increases efficiency of motor up

to 10%. This chart should be used as a guide ONLY.

Speeds will vary due to rotator wear, tubing size or

lengths, etc.

NOTES

>

Never run disk over it's maximum safe

operating speed.

NOTE

>

Air heater removes condensation from

OD of motor at high speeds.

NOTE

AA-07-02.1
