Turbodisk Applicator - Parts Identification
30
Dash #
TABLE "B" - FAIRING
Part #
0
2
--
70158-02
Description
None
Fairing
Dash #
TABLE "D" - HOSE FOR PAINT SYSTEM
Part #
0
4
5
6
--
70977-04
70977-05
70977-06
Description
None
3/8" OD
1/2" OD
1/4" OD
Dash #
TABLE "C" - FLUID CONTROL VALVE KIT
Kit Part #
5
6
7
8
A
B
C
D
E
F
G
H
J
K
M
N
P
R
S
70975-05
70975-06
70975-07
70975-08
70975-09
70975-09
70975-09
70975-09
70975-09
70975-09
70975-09
70975-10
70975-10
70975-10
70975-10
70975-10
70975-10
70975-10
70975-11
DR-1 or
High Flow
Reference
70975-05
70975-06
70171-04
70171-04
74151-01
74151-02
74151-03
74151-04
74151-05
74151-06
74151-11
74151-01
74151-02
74151-03
74151-04
74151-05
74151-06
74151-11
74151-11
Description
No Valves or Fluid Regulator
3-Way Valve, No Fluid Regulator
Trigger Valve with High Flow Fluid Regulator
Trigger & Dump Valve with High Flow Fluid Regulator
Trigger Valve with DR-1 Fluid Regulator, 1:2 Ratio
Trigger Valve with DR-1 Fluid Regulator, 1:4 Ratio
Trigger Valve with DR-1 Fluid Regulator, 1:6 Ratio
Trigger Valve with DR-1 Fluid Regulator, 1:8 Ratio
Trigger Valve with DR-1 Fluid Regulator, 1:10 Ratio
Trigger Valve with DR-1 Fluid Regulator, 1:3 Ratio
Trigger Valve with DR-1 Fluid Regulator, 1:1 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:2 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:4 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:6 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:8 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:10 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:3 Ratio
Trigger & Dump Valve with DR-1 Fluid Regulator, 1:1 Ratio
Trigger & Dump Valve with (2) DR-1 Fluid Regulator, 1:1 Ratio
6
6
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
