Turbodisk Applicator - Parts Identification
48
3
Use as required to increase fluid pressure at regulator outlet to approx. 5-20 psi
Pressue Change Across Tubing (PSI)
≈ .601 X 10 6 X Flow Rate (mi/min) X Viscosity (Poise) X Fluid Length (in)
[Tube ID (in)] 4
Item #
70990-09 TURBODISK ASSEMBLY, TRIGGER VALVE ONLY
W/DR-1 REGULATOR - PARTS LIST (Figure 11)
Part # Description Qty Notes
1 70976-01 Feed Tube Kit, Downfeed 1 Part of 70988-XX Kit
2-1 8156-24F Screw, 5/16-24 X 3/4", Hex Head 2
2-2 8156-32F Screw, 5/16-24 X 1", Hex Head 5
2-3 8156-40F Screw, 5/16-24 X 1-1/4", Heax Head 1
2-4 7734-07 L Washer, Spring, 5/16" 6
2-5 17274-00 High Voltage Connector Assembly 1
2-9 15980-00 Extension Arm, Air Motor 1
2-10 1613-03 Tube Support, 20-3/8" 1
2-11 8156-48F Screw, 5/16-24 X 1-1/2", Hex Head (Not Used) 2
2-12 3923-02 Spiral Wrap, 1/2" (Not Shown) 25'
2-13 27141-081 Hose Wrapping (Not Shown) 25'
Same as TR-SSEM-082
2-14 15946-00 Grounding Hook Assembly (Not Shown) 1
2-15 10384-01 Tubing, Latex, 3/16" ID X 1/16" Wall (Not Shown) 50'
3-1 9704-03 Tubing, LD/PE, 1/4" OD X .17" ID 100'
3-2 7113-13 Tubing, 1/2" OD X .060" Wall, Nylon 50'
3-3 SSP-5020 Tubing, 3/8" OD X 1/4" ID 100' Supplied with Kit 70977-04
only
3-3 55994-26 Tubing, 1/2" OD X 3/8" ID 100' Supplied with Kit 70977-05
only
3-4 78006-00 Elbow, 3/8" OD Tube X 1/4" NPT 2 Supplied with Kit 70977-04
only
3-4 LSFI0005-01 Connector, Straight, 1/2" OD Tube X 1/4" NPT 4 Supplied with Kit 70977-05
only
3-5 41-FTC-1002 Connector, Straight, 3/8" OD Tube X 1/4" NPT 4
4-1 70590-01 Connector, Male, 1/4" OD Tube X 1/4" NPT, SS 1
4-4 LRPM0105 Bracket 1
4-5 CCV-12-SS Valve Adapter 1
4-6 CCV-403-SS Trigger Valve Assembly 1
4-7 SSP-6054 Connector, 1/4" OD Tube X 1/8" NPT, Male, Brass 1
4-8 55994-28 Tubing, FEP, .188" ID X .250" OD 5'
4-9 SSP-1421 Plug, Hex Socket, 1/4" NPT 1
4-13 LSFI0038-00 Elbow, Street, Reducing, 2
1/8" NPTM X 1/4" NPTF, SS
4-14 SSP-6439 Elbow, Swivel, Male, 1/4" OD X 1/4" NPT, Brass 1
4-15 76462-00 Service Tee, NI, 1/4" 1
4-16 LSFI0006-01 Elbow, 1/4" OD Tube X 1/4" NPT,Female, SS 1
These parts are supplied with Kit 70977-04 (3/8" OD) Low Flow or 70977-05 (1/2" OD) High
Flow, Tube & Fitting Kit (Shipped loose as Kit, no assembly)
These parts are supplied with Kit 70973-01 Hardware & Mounting Parts Kit
These parts are supplied with Kit 70975-09 Trigger Valve Kit
(Continued On Next Page)
