DATA LOGGING WITH A COMPUTER
In addition to making and displaying real-time air speed, airflow volume and temperature
measurements and storing up to nine sets of these readings in nonvolatile memory, the
CIH20DL also can make and time-stamp up to 20,000 measurements over extended periods
of time at user-selected sampling rates. These measurements, called data logs, are stored
in a separate internal memory. They can be uploaded to a PC using the USB cable and
interface/driver/data logging software provided with the instrument.
After uploading, the data logs can be analyzed for trends and anomalies using the software’s
presentation options. Examples include graphical and tabular displays of data that make it
easy to spot excursions of air temperature or gradual decreases in airflow volume over time.
Install Software and Drivers
1. Place the installation disc, shiny side
down, in your computer’s CD/DVD
drive and close the drawer.
2. Double-click the icon "Run setup.exe",
or the icon representing the disc to
initiate AutoPlay. The screen shown in
Fig. 9 will appear.
3. Click Next to install the anemometer's
application program (Anemometer AP,
Version 3) in your C:\Program Files
(x86) folder in a new subfolder named
. (If you want to install the
software elsewhere, click Browse and
choose another location.) Doing so will
also install software for other National
Instruments products in another new Program Files subfolder named
Instruments>.
4. On the next dialog box (the National Instruments Software License Agreement),
click the circle to the left of “I accept the License Agreement” and then click Next.
5. On the next dialog box (the License Agreement), again left-click the circle to the left
of “I accept the License Agreement” and then left-click Next.
6. On the next dialog box (Start Installation), click Next. On some computers, the two
software installations may take as long as 20 minutes.
7. When the next dialog box (Installation Complete) notifies you that “The installer has
finished updating your system,” click Next.
8. The next dialog box prepares for installation of the PL-2303 USB-to-Serial driver on
your computer. Click Next to continue.
9. When the next dialog box (InstallShield Wizard Complete) appears, click Finish.
14
Fig. 9. The initial software installation
