24-1
Chapter 24: Configuring Private VLANs
Private VLANs provide port-based security and isolation between ports within the
assigned VLAN. Data traffic on downlink ports can only be forwarded to, and from,
uplink ports. (Note that private VLANs and normal VLANs can exist simultaneously
within the same switch.)
Enabling Private VLANs
Use the Private VLAN Status page to enable/disable the Private VLAN function.
Web – Click VLAN, Private VLAN, Status. Select Enable or Disable from the
scroll-down box, and click Apply.
Figure 24-1 Private VLAN Status
CLI – This example enables private VLANs.
Console(config)#pvlan 53-1
Console(config)#
Uplink Ports
Primary VLAN
(promiscuous ports)
x Downlink Ports
Secondary VLAN
(private ports)
