Section 1: General Information
01/12 8 50647 Rev. 9
1.2. SPECIFICATIONS
Instrument Approvals  NTEP: CoC 01-009
 CWM:
Pending
FM Approvals  Class I, II, and III
 Division
1
 Groups A, B, C, D, E, F, and G
* For more detailed information, see FM Control Drawing 21943.
see Appendix II.
Physical Dimensions Approximately 13"W x 9"H x 3"D
Material Stainless Steel
Enclosure Rating  NEMA 4X
 IP65
Capacities Service programmable up to 999,950 lb, kg, oz, g, tons, lb-oz, or gallons
Division Sizes  Service programmable for .0002 to 50
 Fixed at one (1) oz. in the lb/oz mode
Resolution  Commercial - Up to 10,000 divisions maximum
 Noncommercial - Up to 30,000 divisions maximum
Sensitivity
 1µv/d (microvolt/division)
Load Cells Up to 16 - 350 or 1000 ohm impedance
Load Cell Cable
Length/Wire Gauge  75' maximum
 20 AWG maximum
Display Weight Display
 1.25" height
 7 segment LCD
Status Display
 .38" x 3.73" Alphanumeric LCD
 16 characters - .38" x .191" character size
Zero Range Service programmable - Disabled, 2, or 100%
Auto-Zero-Tracking Service programmable - Disabled, .5, 1, or 3 divisions
Motion Detection Service programmable - Disabled, .5, 1, or 3 divisions
Digital Filter Service programmable from disabled up to heavy
Display Update Rate Service programmable settings from .1 to .8 seconds.
Environment Handbook 44 Compliance Tested Operating Environment
 Temp -10°C to + 40°C (+14°F to + 104°F)
Storage
 Temp -40°C to + 60°C (-40°F to + 140°F)
Chemical Resistance Resistant to all petroleum derivatives and salts.
