01/12 64 50647 Rev. 9
Appendix IV: Continuous Output Data Streams
A. FORMAT: FAIRBANKS COMPUTER (FBPUTR)
Character 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
Data String
STX A B C x x x x x x t t t t t t CR
x
= Displayed weight; Gross or Net
t
= Tare Weight
A
= Status Word A
B
= Status Word B
C
= Status Word C
 Leading zeros are suppressed.
The following tables define the value of Status Word A, B, and C:
A.1. STATUS WORD A
DIVISION SIZE
DECIMAL POINT OR ZERO LOCATION
BIT NO. X0 X 0.X 0.0X 0.00X 0.000X 0.0000X
0 1 0 1 0 1 0 1
1
0 1 1 0 0 1 1
2 0 0 0 1 1 1 1
BIT NO. COUNT BY 1 COUNT BY 2 COUNT BY 5
3 1 0 1
4 0 1 1
5 Always Logic 1
6 Always Logic 0
7 Parity Bit
