Section 3: Programming
01/12 47 50647 Rev. 9
3.5.1. I/O MENU DESCRIPTIONS, CONTINUED
PROMPT CHOICE(S)
SPhAnd The Manual mode of a batching process.
─ Each separate material is operator-selected by using the
SCROLL key, and then pressing START .
─ This sequence must be continued until the batch is complete.
─ If a printer is selected, an auto print occurs when target value is
reached.
─ Further detailed programming includes the following in order to
define this modes operation.
 Gross ( groSS )  Net ( nEt )  Single relays ( SoLo )
 Dual relays ( PAirEd )  Upweighing ( UP )
 Downweighing ( not UP )
 Down weighing is a net mode function and requires an
─ initial weight of zero. The instrument must have an auto tare
performed prior to beginning the setpoint operation.
─ SPhAnd is not available in the Gallons mode.
SPhAnd SPALrt  Used for ALARM purposes.
 Only setpoint-relay (8) is used for both the LOW and HIGH alarms.
 The setpoint-relay actives when the GROSS weight is equal to or
below the programmed LOW ALARM weight value, or equal to or
above the programmed HIGH ALARM weight value.
Set the LAST to the following value, if Paired is selected:
PAIRED LAST
 1  5
 2  6
 3  7
 4  8
Relays (4) and (8) are conditional on selection of the SPALrt feature.
EXITING MENUS When exiting the TARGET or IO menus, either store or canceling the
changes.
─ When prompted to SToRE , press ENTER to save the changes.
─ The display momentarily reads SToRED , and then returns to the
root menu prompt.
─ With SToRE displayed, press the SCROLL key to select the
CANCEL option
─ Press ENTER and no changes are saved.
