Front panel key functions – Fairbanks 2800 Series Intrinsically Safe Instrument User Manual
Page 19
Section 2: Operation
01/12
19
50647 Rev. 9
2.3. FRONT PANEL KEY FUNCTIONS
The function of the front panel keys varies depending on the mode in which the
instrument is operated. This Subsection defines the operation of each front panel key
when in the weighing mode.
ZERO KEY
When in the Gross mode, this key sets the
Gross Weight
to Zero.
─ If motion exists, the
ZERO
command will not be executed.
─ If the weight on the platform exceeds the zero limit, and the
ZERO key
is
pressed, the Zero command will not be executed.
PRINT KEY
Used to transmit weight data to an external device.
GROSS/NET KEY
Toggles between the Gross and Net Weight modes.
─ It is also used to exit programming.
