Installation – Fulton Pulse HW (PHW) Fully Condensing Hydronic Boiler User Manual
Page 10
© The Fulton Companies 2013
INSTALLATION
PHW-IOM-2013-0214
SECTION 2
2-4
TABLE 1 - BOILER DIMENSIONS AND OPERATING REQUIREMENTS
Model
PHW
300
500
750
1000
1400
2000
Specifi cations
Input
BTU/Hr
300,000
500,000
750,000
1,000,000
1,400,000
2,000,000
Nat. Gas consumption @ rated
capacity
FT3/Hr
300
500
750
1000
1400
2000
Propane Consumption @rated
capacity
FT3/Hr
120
200
300
400
560
720
Electrical Requirements
120V/60/1
4.2/0.6
4.2/0.6
4.2/0.6
4.2/0.6
4.2/0.6
10/.75
(Amps: Max/Run)
240V/60/1
2.1/0.3
2.1/0.3
2.1/0.3
2.1/0.3
2.1/0.3
5/0.4
MAWP
PSI
160
160
160
160
160
160
BAR
4.1/11.0
4.1/11.0
4.1/11.0
4.1/11.0
4.1/11.0
4.1/11.0
Water Content
Gal
34
34
42
42
80
75
Dry Weight
LB
1395
1395
1800
1800
2230
2900
Operating Weight
LB
1680
1680
2150
2150
3195
3500
Dimensions
A. Boiler Width
IN
27.5
27.5
27.5
27.5
33.6
33.6
B. Overall Boiler Height
IN
71.25
71.25
83.2
83.2
88.1
89
C. Overall Boiler Depth
IN
53.25
53.25
51.3
51.3
62.6
70.1
D. Exhaust Outlet Diameter
IN
4
4
4
4
4
6
E. Air Inlet Diameter
IN
3
3
4
4
4
6
F. Water Inlet/ Outlet Diameter
IN
2
2
2
2
2.5
4 Flanged
G. Min. Clearance to Ceiling
IN
24
24
24
24
24
24
H. Min. Clearance to Either Side Wall
IN
1
1
1
1
1
1
I. Min. Clearance in Front of Boiler
IN
36
36
36
36
36
36
J. Min. Clearance Behind Boiler
IN
24
24
24
24
24
24
FIGURE 2 -PULSE COMBUSTION HYDRONIC BOILER
Back View
Front View
Top View
A
C
D
B
G
E
H
F
F
I
J
